The Hollyland Arocam C2 is a compact and powerful PTZ camera, specially designed for live streaming, live commerce, live shopping, and video meeting.

The cutting-edge auto instantaneous focus and its ranging function virtually eliminate distracting image blurring so your audience experiences a near-live view of the product or subject's details. Featuring wide-angle rotations and fabulous image quality, its interfaces support simple settings and operations that are perfectly applicable to extended live production.

  • Portrait Mode
  • Auto Focus
  • Remote Control
  • 12x Optical Zoom
  • Pro Color Mode
  • Multi-Camera Live Streaming

Live streaming, live commerce, live shopping, video meeting

Auto Instantaneous Focus

Featuring a cutting-edge focusing algorithm and a 3D-ranging ToF module, the camera provides quick, accurate, and stable focusing.

72.5° Wide-Angle Lens and 12x Optical Zoom

With its 72.5° wide-angle lens and 12x optical zoom, the camera is perfectly adaptable to panorama and close-up shooting applications.

Portrait Mode for Mobile Live Streaming

Besides the traditional landscape output, the C2 also offers a portrait mode that innovatively adapts to mainstream live streaming applications.

Pro Color Mode & HD Image Quality

The camera supports a 10-bit 4:2:2 professional color mode. This superior color sample rate helps realize a more robust original color rendition. A high-quality 1/2.8-inch HD CMOS sensor supports a maximum resolution of 1920x1080, providing a very pleasing visual experience. Noise reduction and backlight compensation enhancements also deliver professional image output.

Brilliant Image Formation Under Low Illumination

The new CMOS image sensor effectively reduces unwanted noise under low illumination. 2D and 3D noise reduction algorithms are employed to effectively improve SNR (55dB) for a clear image when shooting is performed in low-light production conditions.

Wide-Angle Rotation by RS232 Remote Control

The horizontal panning range is 340° and the vertical tilting range is 120°. Remote control of the camera rotation is possible via its RS232 serial port.

Rich Interfaces for Different User Requirements

The C2 supports various interfaces, such as the USB interface, HDMI interface, and network interface, for wide compatibility. The USB interface supports the UVC and UAC protocols, the HDMI interface enriches the monitoring forms, and the network interface is used for camera settings.

Packing List
Name Quantity
Camera 1
Power Adapter 1
Remote Control 1
User Manual 1
Output Format 1080P60, 1080P50, 1080P30, 1080P25, 720P60, 720P50
Sensor 1/2.8 inch, CMOS, Max Effective Pixel: 2.07M
Scanning Mode Progressive
Lens 12x, f = 3.5mm–42.3mm, F1.8–F2.8
Minimum Illumination 0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s–1/10000s
White Balance Mode Auto, Indoor, Outdoor, One Push, Manual, VAR
Backlight Compensation Supported
Digital Noise Reduction 2D & 3D Digital Noise Reduction
SNR ≥55dB
Horizontal Angle of View 6.9°–72.5°
Vertical Angle of View 3.9°–44.8°
Horizontal Rotation Range 340°
Vertical Rotation Range 120°
Panning Speed Range 2.7°–35.7°/s
Tilting Speed Range 2.7°–31.5°/s
H & V Flip Supported
Image Freeze Supported
Number of Presets 255
Preset Accuracy 0.1°
USB Features
OS Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android
Color System/Compression 1/2.8 inch, CMOS, Max Effective Pixel: 2.07M
Scanning Mode YUY2/MJPEG
Output Video Format ·YUY2: 1080P@30fps (max.) ·MJPEG: 1080P@30fps (max.)
USB Audio Communication Protocol UAC1.0
USB Video Communication Protocol UVC 1.1
UVC PTZ Supported
Network Features
Video Compression H.264/ MJPEG
Video Stream First/Second Stream
First Stream Resolution 1920x1080, 1280x720
Second Stream Resolution 1280x720, 640x360
Bit Rate for First Stream 32Kbps–20480Kbps
Bit Rate for Second Stream 32Kbps–6144Kbps
Bit Rate Control CBR, VBR
Frame Rate 50Hz: 1fps–50fps, 60Hz: 1fps–60fps
Audio Compression AAC
AAC 96Kbps, 128Kbps, 256Kbps
Network Protocols TCP/IP, HTTP, RTSP, RTMP(S), ONVIF, DHCP, Multicast, etc.
Input/Out Interfaces
Line Input Interface 1 x Line Input: 3.5mm Line Input Interface
Communication Interface 1 x RS232 IN: 8pin Min DIN, Max Distance: 30m,Protocol: VISCA/Pelco-D/Pelco-P
Network Interface 1 x NET: 10M/100M Adaptive Ethernet Port
USB Interface 1 x USB 3.0: Type C
HDMI Interface 1 x HDMI: Version 1.4b
Power Jack DC (DC 12V)/USB Type-C (5V)
Power, Temperature, Measures, and Weight
Input Voltage DC 12V/USB 5V
Input Current 12V 1.0A (max.)/5V 1.5A (max.)
Operating Temperature –10℃ to 40℃
Storage Temperature –40℃ to 60℃
Power Consumption 12W (max.)
Dimension 142.2x151.9x175.8mm (5.6"x6"x6.9")
Net Weight 1.5kg (52.9oz)
