Pyro Ultra
Buy

Highlights Overview.

1TX & Unlimited RX
4K60 UHD
focus Mode
Proprietary TWiFi
Technology
Pyro Ecosystem
DFS Certified
UVC & RTMP Steaming
HDMI & SDI Flexibility
Broadcast Mode
With broadcast mode enabled, Pyro Ultra delivers real-time monitoring across an unlimited number of receivers with smooth, reliable clarity. The standard setup supports up to 6 monitoring screens (4 receivers and 2 mobile apps), offering just the right coverage for lean teams.
Activated
Deactivated
Your Vision      Ultra Clear
UHD Resolution
4K60
High Transmission Rate
12 Mbps
Proprietary Codec Technology
TWiFi
Just right. Just 4K60. With support for true 4K60 at 12 Mbps over HDMI, Pyro Ultra leverages the powerful TWiFi codec to render each moment with stunning clarity, nuance, and depth.
For focus pulling, down to 20ms[2]. When enabled, Focus Mode reduces latency on enabled devices to as low as 20 ms, so every pull feels precise and responsive. Whether you're catching a subtle glance, pulling focus on a moving subject, or tracking a quiet moment, everything lands right on cue. The rest of your system flows just as smoothly.
So Far. So Ultra.
TWiFi
TWiFi
TWiFi
TWiFi
TWiFi
TWiFi
TWiFi
Transmission Technology
Enjoy Wider Access
DFS Ready
Pyro Ultra supports Dynamic Frequency Selection (DFS)-enabled bands, unlocking more spectrum for wireless transmission in regulated regions[4]. More flexibility. Fewer restrictions. Wherever your production takes you.
Flexible Streaming Solutions
Stream it your way.
Pyro Ultra features UVC and RTMP streaming, enabling high-quality capture up to 4K60 with plug-and-play ease and flexible platform connectivity, perfect for live production and remote collaboration.[5]
UVC
RTMP
The Pyro Ecosystem
Pyro All-ways.
Pyro Ultra is fully compatible with our Pyro lineup[6], including Pyro H, Pyro S, Pyro 7, Pyro 5, and even Vcore, forming a true ecosystem of cross-device integration. Whether you're upgrading your system or mixing setups on set, every link fits smoothly into the chain.
Freeze Frame
Unexpected cut? No worries. Pyro Ultra freezes the last frame on screen, giving crews time to recover without disrupting the workflow. For added flexibility, you can set a custom image[7] as the fallback display to maintain visual consistency and brand presence.
Output Image
Custom Image
Versatile Connectivity
HDMI & SDI with frame rate flexibility. The Pyro Ultra transmitter supports 4K60 HDMI loop out, so you can monitor footage locally without compromise. With support for fractional frame rates on both HDMI and SDI, it adapts smoothly to professional and broadcast standards, so your setup stays flexible across productions.
TVC
Commercial
Production
Display Screen
Joystick Button
Power Button
DC Power Input
USB-C Port
HDMI OUT
SDI Out
NP-F Battery Plate
USB-C Port
HDMI Input
HDMI Loopout
SDI Input
V-Mount Battery Plate
Display Screen
Joystick Button
Power Button
DC Power Input
Display Screen
Joystick Button
Power Button
DC Power Input
NP-F Battery Plate
USB-C Port
HDMI Input
HDMI Loopout
SDI Input
USB-C Port
HDMI OUT
SDI Out
V-Mount Battery Plate
Display Screen
Joystick Button
Power Button
DC Power Input
Adaptive Output Resolution
One signal. Multiple displays. Receivers automatically adapt output resolution to match downstream devices. Even when transmitting in 4K60, a receiver can output in 1080p, ensuring compatibility across setups while preserving the integrity of the source signal.
Pyro Ultra
Link Infinite
1 TX & Unlimited RX
4K60 HUD
Focus Mode
Proprietary TWiFi Technology
Pyro Ecosystem
DFS Certified
UVC & RTMP Streaming
HDMI & SDI Flexibility
Buy Now
Your Package List
Transmitter TX
Receiver RX
1TX & 1RX
1TX & 2RX
Transmitter x 1
Easy-Install Short Antenna x 4
USB-C OTG Adapter x 1
1/4″ Cold Shoe x 1
Receiver x 1
Easy-Install Short Antenna x 4
USB-C OTG Adapter x 1
12V/2A DC Power Adapter x 1
Transmitter x 1
Receiver x 1
Easy-Install Short Antenna x 4
Easy-Install Antenna x 4
12V/2A DC Power Adapter x 1
USB-C OTG Adapter x 1
Double Ball Head with Cold Shoe Mount x 1
D-Tap to Locking DC Power Cable x 1
Transmitter x 1
Receiver x 2
Easy-Install Short Antenna x 4
Easy-Install Antenna x 8
12V/2A DC Power Adapter x 1
USB-C OTG Adapter x 1
Double Ball Head with Cold Shoe Mount x 1
D-Tap to Locking DC Power Cable x 1
Upgrade Your Setup.
Pyro Ultra Transmitter
Pyro Ultra Receiver
Easy-Install Short Antenna
Easy-Install Antenna
USB-C OTG Adapter
Specs
Transmitter
Receiver
Transmitter
Receiver
Interfaces
DC IN: 2.0 Barrel Connector
HDMI IN: HDMI 2.0
HDMI LOOPOUT: HDMI 2.0
SDI IN: 3G SDI
Type-C: USB 2.0
Antenna: SMA Male Connector
DC IN: 2.0 Barrel Connector
HDMI OUT: HDMI 2.0
SDI OUT: 3G SDI
Type-C: USB 3.0
Antenna: SMA Male Connector
Power Supply Voltage Range
Battery Power Input: 6.8-8.4V
DC Power Input: 6-16V
Battery Power Input: 6.8-8.4V
DC Power Input: 6-16V
Power Consumption
Non-broadcast: 11W
Broadcast: 14W
7W
Net Weight
320g
320g
Dimensions
(L*W*H): 124.5*80*34.9mm
(L*W*H): 124.5*80*34.9mm
TX Power
< 23dBm
/
RX Sensitivity
/
Non-broadcast: -85dBm
Broadcast: -80dBm
Input/Output Video Formats
HDMI:
720p50/59.94/60
1080p23.98/24/25/29.97/30/50/59.94/60
4k(3840*2160)23.98/24/25/29.97/30/50/59.94/60

SDI:
720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.97/30/50/59.94/60
HDMI:
720p50/59.94/60
1080p23.98/24/25/29.97/30/50/59.94/60
4k(3840*2160)23.98/24/25/29.97/30/50/59.94/60

SDI:
720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.97/30/50/60
Operating Frequency[8]
5G
5.150 – 5.250 GHz
5.250 – 5.350 GHz
5.470 – 5.725 GHz
5.725 – 5.850 GHz

2.4G
2.412 – 2.484 GHz
5G
5.150 – 5.250 GHz
5.250 – 5.350 GHz
5.470 – 5.725 GHz
5.725 – 5.850 GHz

2.4G
2.412 – 2.484 GHz
Transmission Latency
Focus Mode: 1080p25 ≥ 20ms
Focus Mode: 1080p25 ≥ 20ms
Bandwidth
20MHz (Broadcast: 40 MHz)
20MHz (Broadcast: 40 MHz)
Note:
 1.
Stable performance is ensured with up to 20 receivers. Additional connections are supported but may vary depending on the actual environment.
 2.
Focus Mode can be enabled on all receivers within the same group. Minimum latency under standard test conditions: ≥20 ms at 1080p25/30, ≥40 ms at 1080p60, and ≥45 ms at 4K60. Latency values apply only when Focus Mode is enabled.
 3.
In Broadcast Mode, the maximum transmission range is 2,300 ft (700 m). In Non-Broadcast Mode, the maximum transmission range extends up to 4,900 ft (1.5 km).
 4.
Actual frequency availability may vary based on local laws and regulations.
 5.
Actual capture resolution depends on the settings of the receiver. UVC supports resolutions up to 4K60, while RTMP streaming is limited to 1080p60.
 6.
Within the Pyro ecosystem, Pyro 5, and Pyro 7 are compatible in both broadcast and non-broadcast modes. Pyro H and Vcore are compatible in non-broadcast mode only. Pyro S currently supports non-broadcast mode only; compatibility with broadcast mode will be added in future firmware updates.
 7.
The custom image must be 1920×1080 (JPG), less than 1 MB, and named “logo.jpg”.
 8.
The product's operating frequency and wireless transmission power may vary depending on the regulations of different countries and regions. Please refer to local laws and regulations for details.
