Interconnection: Solidcom C1 & Syscom 1000T

March 27, 2023

Solidcom C1 & Syscom 1000T

AS-220527158

1. Connection


① 4 Wire interface of Solidcom C1

② Customize Network Cable to dual XLR cable

③ 2 XLR 4 Wire interface of Syscom 1000T

Interconnection: Connect the HUB with a standard network cable through 4 Wire interface.

Solidcom C1 4W pin out:


2. Setting:

Solidcom C1 4W setting set to 【Cross】
