Diagram:
① 2-wire interface on the Solidcom C1 Pro
② Standard 3-pin XLR cable
③ (Intercom Channel A/B) 3-pin XLR interface on the Clear-Com 702
Connection:
Use the male connector of a standard XLR cable to connect to the 2-wire interface on the Solidcom C1 Pro hub and the female connector to connect to one of the Intercom Channel A/B interfaces on the Clear-Com 702.
Settings:
① Press and hold the button on the Solidcom C1 Pro hub to enter the menu interface.
② Select 2 Wire.
③ After you select Terminal Res, if you can hear the echo from the Clear-Com 702, you can select Auto Null for calibration.
FAQs:
Question 1:
What should I do if the sound from the Solidcom C1 Pro is too quiet?
Answer:
Enter the menu interface on the Solidcom C1 Pro hub and perform 2-wire settings as follows:
Output Gain: Set Gain to 6dB, 12dB, or 18dB.
Question 2:
What should I do if the sound from the Clear-Com 702 is too quiet?
Answer:
Enter the menu interface on the Solidcom C1 Pro hub and perform 2-wire settings as follows:
Input Gain: Set Gain to 6dB, 12dB, or 18dB.
