1) Cascade Within Solidcom C1 Pro Hub-based Systems:
Cascade via the 4-wire interface:
Connection:
Connect two hub-based systems through the 4-wire interface via a standard network cable. The maximum length of the network cable is 300 meters.
4-wire settings:
After the connection, enter the 4 Wire Setting interface on the hub, select Line Sequence Switching, and
set one system as Standard and the other as Cross.
Setup steps:
Cascade via the RJ45 interface:
Connection:
Connect two hub based systems through the RJ45 interface via a standard network cable.
The maximum length of the network cable is 300 meters
Three hub-based systems are recommended for cascade via an IP network. One system is set to Master
Device, and the other two are set to Slave Device. The settings steps are the same as those described in
the 5.2 section.
Settings:
After two systems are connected to each other via a network cable, select Master And Slave and set the systems as the master device or slave device. Generally, one system is set as Master Device and the other is set as Slave Device. Select Scan and then select the IP address of the master device.
Note: The IP Address Automatic switch must be turned off under Network Settings->IP Address Settings
on the two hub-based systems.
Setup steps:
