Interface Connection & Installation introduction

March 27, 2023

OVERVIEWS: Mars M1 has rich interface, this article shows the usage of all the interface for your reference.

NumFeaturesDetails
Micro-single CameraSONY, Canon, Fuji, Nikon
Video CameraPanasonic, SONY
CinematographARRI, RED, SONY Telecine Camera
Sun ShieldShield from direct sunlight when used outdoors
MonitorConnect to big monitor to review
Hand ShankMount it to handle the Mars M1 easily
USB DiskConnect USB flash disk to upgrade.
NumFeaturesDetails
DC OUT to CameraDC OUT to power the camera (Also work when power by battery)
D-Tap to DCPower by V-mount / G-mount battery
DC AdapterPowre by DC Adapter (6~16V)
Shoulder GirdleMount it to hang Mars M1 over your shoulder
TripodMount it to the tripod when using as RX
Cold shoe to CameraMount it on the camera cold shoe when using as TX
Camera SDI INCamera SDI input only work when using as TX
NP-F BatteryNPF970, NPF750, NPF550 battery
Article Number: 【AS-220623167_8】
